Name: Turbo Type M25 Replacement TKISM025N02 for 3/4'' 1'' Turbo Diaphragm Repair Kit
Brand: Ningbo Brando Hardware Co., Ltd
SKU: M25
Price: 49.10 USD
Availability: InStock

Inicio Productos Equipo de reparación del diafragma

Turbo Type M25 Replacement TKISM025N02 for 3/4'' 1'' Turbo Diaphragm Repair Kit

Datos del producto:

Lugar de origen:	Porcelana
Nombre de la marca:	Ningbo BRANDO
Certificación:	None
Número de modelo:	M25

Pago y Envío Términos:

Cantidad de orden mínima:	1 juego
Precio:	Negociable
Detalles de empaquetado:	Cajas interiores, cajas de cartón, palés
Tiempo de entrega:	7 días laborables
Condiciones de pago:	T/T, Unión Occidental, Paypal
Capacidad de la fuente:	100000 unidades por mes

Contacto

Descripción detallada del producto

Nombre del producto:	Diafragma de válvula de pulso	Material del diafragma:	NBR, Viton
Puerto de válvula de pulso ajustado:	3/4 '', 1 ''	Modelo de válvula de pulso ajustado:	FP20, FM20, FP25, FM25, DP20, DM20, DP25, DM25, EP25, EM25, SQP20, SQM20, SQP25, SQM25, FDP20, FDM20
1 juego:	diafragma de 1pc M25, primavera 1pc
Resaltar:	Turbo M25 Replacement , 1'' Turbo Diaphragm Repair Kit , Diaphragm Repair Kits M25 for Turbo Valves

Turbo Type M25 Replacement TKISM025N02 for 3/4'' 1'' Turbo Diaphragm Repair Kit

M25 Diaphragm (Membrane) for Turbo pulse valve FP20, FM20, FP25, FM25, DP20, DM20, DP25, DM25, EP25, EM25, SQP20, SQM20, SQP25, SQM25, FDP20, FDM20, FDP25, FDM25; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse Jet Valve is a solenoid pilot operated diaphragm valve specially designed to deliver extremely fast pulsing in reverse-jet dust collector systems. With its high flow rates, higher peak pressure and the fastest response times on the market it delivers optimal filter cleaning performance, while using significantly less air. This results in energy savings for the user.

Ordering Code of Diaphragm For Turbo Pulse Valve:

Ordering code	Fitted valve code	Valve port size	Material
M25	FP20, FM20, FP25, FM25, DP20, DM20, DP25, DM25, EP25, EM25, SQP20, SQM20, SQP25, SQM25, FDP20, FDM20, FDP25, FDM25	3/4'', 1''	NBR
M40 + M25	FP40, FM40, DP40, DM40, EP40, EM40	1 1/2''	NBR
M50 + M25	FP50, FM50, FP55, FM55, SQP50, SQM50, SQP55, SQM55, SQP60, SQM60, SQP65, SQM65	2'', 2 1/2''	NBR
M75 + M25	FP65, FM65, SQP75, SQM75, SQP100, SQM100	2 1/2'', 3''	NBR
Tips: EPDM, FKM all available.

Dimension of M25 Diaphragm:

Turbo Type M25 Replacement TKISM025N02 for 3/4'' 1'' Turbo Diaphragm Repair Kit 0

Video of M25 Diaphragm:

Pictures of Pulse Valve Membrane Production:

More Turbo Type Pulse Jet Valve for you to choose:


Threaded Type	Submerged Type	Valve Diaphragm

Solenoid Coil	Solenoid Armature	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
