SBFEC Type New Version Solenoid Coil For DMF Series Pulse Valve 24VDC DC24V

SBFEC Type New Version Solenoid Coil For DMF Series Pulse Valve 24VDC DC24V

The DMF-Z solenoid/diaphragm valve is kind of vertical-angle valve, with an included angle of 90° between inlet and outlet. It simplifies the connection between gas bag and blowing tube of a dust collector. It can provide stronger airflow and meet dust removing requirements.
The DMF-Y solenoid/diaphragm valve is kind of
submerged valve (namely, insert valve), which is installed directly on a secondary gas bag and achieves better circulation quality. The valve has less pressure loss, and is applicable to the operations with lower gas pressure.
The DMF-ZM Solenoid/Diaphragm valve pulse jet valve is kind of vertical-angle valve similar to the z-series valves, suitable for connection between gas bag and blowing tube of a dust collector. It has fixed nuts for installation purposes at the inlet and outlet end, for easier installation and application.
The DMF-T solenoid/diaphragm valve is kind of through valve, with an included angle of 180° between the inlet and outlet (central line of both inlet and outlet are the same straight line). Also, the inlet is connected to a gas storage tank, while its outlet is connected to a blowing tube.

Hole Size:13.5mm
Height:41.2mm
Width:36.0mm
Voltages:AC220V, DC24V
Power:25VA, 20W
Connection Type:DIN43650A
Protection Grade:IP65
Insulation Class:F, H
Enameled wire material:Copper
Application:SBFEC Type New DMF Series Pulse Valve

Dimension:

Technical Data:

Why Choose Us:

Ningbo Brando Hardware is professional solenoid valve and solenoid valve repair kit manufacturer. After years of constant innovation and development, the development of products stable performance, reliable quailty. Foucus on quality, meticulous. Details determine success failure. Advanced processing equipment, reliable quality assurance, first-class testing equipment. Technology as support to technology as the basis, implementing the full sense of quality.

Product Characteristic:
1. Using high quality wire which has UL approved;
2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on;
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on;
7. If you have special requirement, pls feel free to contact us.
