| Lugar de origen: | Porcelana |
| Nombre de la marca: | BRANDO |
| Certificación: | None |
| Número de modelo: | DB120 |
| Cantidad de orden mínima: | 1 juego |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Bolsa de plástico, caja, cartón, palé |
| Tiempo de entrega: | Entre 4 y 7 días hábiles |
| Condiciones de pago: | T/T, Unión Occidental, Paypal |
| Capacidad de la fuente: | 100000 conjuntos por mes |
| Nombre del producto: | Membrana de válvula de pulso | Material de membrana: | NBR, FKM |
|---|---|---|---|
| 1 juego: | diafragma de 1pc DB120, diafragma de 1pc DB16, primaveras 2pcs | Modelo de válvula de pulso ajustado: | VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM72 |
| Resaltar: | Mecair Diaphragm DB120/C,Mecair Membrane DB120/C,Mecair DB120 |
||
DB120 DB120/C Diaphragm Repair Kit for Mecair Pulse Jet Valve VNP220 VEM220 VNP420
DB120 ( DB120/C ) Diaphragm ( Membrane ) for Mecair pulse valve VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM72; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. On a pulse jet baghouse pulse valves (also called diaphragm valves) control the release of air pulses during the cleaning cycle. When the baghouse control board or timer board initiates a cleaning cycle it sends an electrical signal to the solenoids, when then activate the pulse valve. Inside the pulse valve, a rubber diaphragm opens and closes to release the compressed air stored in the air header tank. The air then passes through the valve into the blow pipes above the filters and then is directed down into the filters to clean them.
Ordering Code of Diaphragm For Mecair Pulse Valve:
|
Ordering code
|
Fitted valve code
|
Valve port size
|
Material
|
|
DB16/G
|
VNP206, VEM206, VNP306, VEM306
|
3/4''
|
NBR
|
|
DB18/G
|
VNP208, VEM208, VNP308, VEM308,
VNP408, VEM408
|
1''
|
NBR
|
|
DB18M
|
VNP608, VEM608, VNP708, VEM708
|
1'', 1-1/2''
|
NBR
|
|
DB112/G
|
VNP212, VEM212, VNP312, VEM312,
VNP412, VEM412
|
1-1/2''
|
NBR
|
|
DB114/C
|
VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714 |
1-1/2''
|
NBR
|
|
DB116/C
|
VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716 |
2''
|
NBR
|
|
DB120/C
|
VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM720 |
2-1/2'', 3''
|
NBR
|
|
Tips: EPDM, FKM all available.
|
|||
Dimension of DB120 Diaphragm:
![]()
Video of DB120 Diaphragm:
Pictures of Pulse Valve Membrane Production:
![]()
More Products For Mecair Pulse Valve for you to choose:
| Valve Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
