Name: Mecair Type DB114 DB114/C Diaphragm For 1-1/2'' VNP214 VNP314 VNP414 Pulse Valve Replacement Kit
Brand: Ningbo Brando Hardware Co., Ltd
SKU: DB114
Price: 49.10 USD
Availability: InStock

Inicio Productos Equipo de reparación del diafragma

Mecair Type DB114 DB114/C Diaphragm For 1-1/2'' VNP214 VNP314 VNP414 Pulse Valve Replacement Kit

Datos del producto:

Lugar de origen:	Porcelana
Nombre de la marca:	Brando
Certificación:	None
Número de modelo:	DB114

Pago y Envío Términos:

Cantidad de orden mínima:	1 juego
Detalles de empaquetado:	Bolsa de plástico, caja, cartón, palé
Tiempo de entrega:	Entre 4 y 7 días hábiles
Condiciones de pago:	T/T, Unión Occidental, Paypal
Capacidad de la fuente:	100000 conjuntos por mes

Contacto

Descripción detallada del producto

Nombre del producto:

Membrana de válvula de pulso

Material de membrana:

NBR, Viton

1 juego:

diafragma de 1pc DB114, diafragma de 1pc DB16, primaveras 2pcs

Modelo de válvula de pulso ajustado:

VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714

Resaltar:

Mecair Diaphragm DB114/C

Mecair Membrane DB114/C

Mecair Pulse Valve Membrane

Mecair Type DB114 DB114/C Diaphragm For 1-1/2'' VNP214 VNP314 VNP414 Pulse Valve Replacement Kit

DB114 ( DB114/C ) Diaphragm ( Membrane ) for Mecair pulse valve VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse valves are operated by integral solenoid pilot operator. When the valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pilot operated valve is de - energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the valve.

Ordering Code of Diaphragm For Mecair Pulse Valve:

Ordering code	Fitted valve code	Valve port size	Material
DB16/G	VNP206, VEM206, VNP306, VEM306	3/4''	NBR
DB18/G	VNP208, VEM208, VNP308, VEM308, VNP408, VEM408	1''	NBR
DB18M	VNP608, VEM608, VNP708, VEM708	1'', 1-1/2''	NBR
DB112/G	VNP212, VEM212, VNP312, VEM312, VNP412, VEM412	1-1/2''	NBR
DB114/C	VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714	1-1/2''	NBR
DB116/C	VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716	2''	NBR
DB120/C	VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM720	2-1/2'', 3''	NBR
Tips: EPDM, FKM all available.

Dimension of DB114 Diaphragm:

Mecair Type DB114 DB114/C Diaphragm For 1-1/2'' VNP214 VNP314 VNP414 Pulse Valve Replacement Kit 0

Video of DB114 Diaphragm:

Pictures of Pulse Valve Membrane Production:

More Products For Mecair Pulse Valve for you to choose:


Valve Diaphragm	Solenoid Coil	Solenoid Armature	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
