Name: DB112 DB112/G Diaphragm Repair Kit For Mecair Pulse Valve VNP212 VNP312 VNP412
Brand: Ningbo Brando Hardware Co., Ltd
SKU: DMF-Y-50S
Price: 49.10 USD
Availability: InStock

Inicio Productos Equipo de reparación del diafragma

DB112 DB112/G Diaphragm Repair Kit For Mecair Pulse Valve VNP212 VNP312 VNP412

Datos del producto:

Lugar de origen:	Porcelana
Nombre de la marca:	Brando
Certificación:	None
Número de modelo:	DMF-Y-50S

Pago y Envío Términos:

Cantidad de orden mínima:	1 juego
Precio:	Negociable
Detalles de empaquetado:	Bolsa de plástico, caja, cartón, palé
Tiempo de entrega:	Entre 4 y 7 días hábiles
Condiciones de pago:	T/T, Unión Occidental, Paypal
Capacidad de la fuente:	100000 conjuntos por mes

Contacto

Descripción detallada del producto

Nombre del producto:

Membrana de válvula de pulso

Material de membrana:

NBR, Viton

1 juego:

1 diafragma DB112, 1 resorte.

Modelo de válvula de pulso ajustado:

VNP212, VEM212, VNP312, VEM312, VNP412, VEM412

Resaltar:

DB112/G Diaphragm

Mecair DB120/G Membrane

Mecair DB120 Diaphragm

DB112 DB112/G Diaphragm Repair Kit For Mecair Pulse Valve VNP212 VNP312 VNP412

DB112 ( DB112/G ) Diaphragm ( Membrane ) for Mecair pulse valve VNP212, VEM212, VNP312, VEM312, VNP412, VEM412; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse valve, also called diaphragm valve acts as a "switch" for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse jet control device. This system cleans the filter bags cluster by cluster with high-pressure blowing to keep the pressure resistance of the baghouse within a pre-set range, and thus ensure the processing capability and the dust-collecting efficiency of the baghouse.

Ordering Code of Diaphragm For Mecair Pulse Valve:

Ordering code	Fitted valve code	Valve port size	Material
DB16/G	VNP206, VEM206, VNP306, VEM306	3/4''	NBR
DB18/G	VNP208, VEM208, VNP308, VEM308, VNP408, VEM408	1''	NBR
DB18M	VNP608, VEM608, VNP708, VEM708	1'', 1-1/2''	NBR
DB112/G	VNP212, VEM212, VNP312, VEM312, VNP412, VEM412	1-1/2''	NBR
DB114/C	VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714	1-1/2''	NBR
DB116/C	VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716	2''	NBR
DB120/C	VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM720	2-1/2'', 3''	NBR
Tips: EPDM, FKM all available.

Dimension of DB112 Diaphragm:

DB112 DB112/G Diaphragm Repair Kit For Mecair Pulse Valve VNP212 VNP312 VNP412 0

Video of DB112 Diaphragm:

Pictures of Pulse Valve Membrane Production:

More Products For Mecair Pulse Valve for you to choose:


Valve Diaphragm	Solenoid Coil	Solenoid Armature	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
