Name: DB18M Diaphragm Repair Kit For Mecair Pulse Jet Solenoid Valve VNP608 VNP708
Brand: Ningbo Brando Hardware Co., Ltd
SKU: DB18M
Price: 49.10 USD
Availability: InStock

Inicio Productos Equipo de reparación del diafragma

DB18M Diaphragm Repair Kit For Mecair Pulse Jet Solenoid Valve VNP608 VNP708

Datos del producto:

Lugar de origen:	Porcelana
Nombre de la marca:	Brando
Certificación:	None
Número de modelo:	DB18M

Pago y Envío Términos:

Cantidad de orden mínima:	1 juego
Precio:	Negociable
Detalles de empaquetado:	Bolsa de plástico, caja, cartón, palé
Tiempo de entrega:	Entre 4 y 7 días hábiles
Condiciones de pago:	T/T, Unión Occidental, Paypal
Capacidad de la fuente:	100000 conjuntos por mes

Contacto

Descripción detallada del producto

Nombre del producto:

Diafragma de válvula de pulso

Material de diafragma:

NBR, FKM

1 juego:

1 diafragma DB18M, 1 resorte.

Modelo de válvula de pulso ajustado:

VNP608, VEM608, VNP708, VEM708

Resaltar:

Mecair Diaphragm Kit DB18M

Mecair Membrane Kit DB18M

Mecair Diaphragm

DB18M Diaphragm Repair Kit For Mecair Pulse Jet Solenoid Valve VNP608 VNP708

DB18M Diaphragm ( Membrane ) for Mecair pulse valve VNP608, VEM608, VNP708, VEM708; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse Jet valves are indirect type solenoid valves. When the solenoid of pulse jet valves gets energized, air trapped in the diaphragm is exhausted causing pressure difference in the diaphragm. Then the diaphragm is suddenly opened. When it is de-energized, air passes through the hole to the chamber which can balance the air pressure and close the valve. The opening and closing of the valve are done very fast for filter cleaning and consumption of compressed air effectively.

Ordering Code of Diaphragm For Mecair Pulse Valve:

Ordering code	Fitted valve code	Valve port size	Material
DB16	VNP206, VEM206, VNP306, VEM306	3/4''	NBR
DB18	VNP208, VEM208, VNP308, VEM308, VNP408, VEM408	1''	NBR
DB18M	VNP608, VEM608, VNP708, VEM708	1'', 1-1/2''	NBR
DB112	VNP212, VEM212, VNP312, VEM312, VNP412, VEM412	1-1/2''	NBR
DB114 + DB16	VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714	1-1/2''	NBR
DB116 + DB16	VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716	2''	NBR
DB120 + DB16	VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM720	2-1/2'', 3''	NBR
Tips: EPDM, FKM all available.

Dimension of DB18M Diaphragm:

DB18M Diaphragm Repair Kit For Mecair Pulse Jet Solenoid Valve VNP608 VNP708 0

Pictures of Pulse Valve Membrane Production:

More Products For Mecair Pulse Valve for you to choose:


Valve Diaphragm	Solenoid Coil	Solenoid Armature	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
