Goyen Type K5004 K5000 K5002 K5005 Diaphragm Repair Kit For Pulse Valve CA50T CA62T

Goyen Type K5004 K5000 K5002 K5005 Diaphragm Repair Kit For Pulse Valve CA50T CA62T

K5004 (M1638A), K5002 (M1639A), K5005 (M1639A), K5000 Diaphragm for Goyen pulse valve CA50T, RCA50T, CA62T, RCA62T; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse Jet valves are indirect type solenoid valves. When the solenoid of pulse jet valves gets energized, air trapped in the diaphragm is exhausted causing pressure difference in the diaphragm. Then the diaphragm is suddenly opened. When it is de-energized, air passes through the hole to the chamber which can balance the air pressure and close the valve. The opening and closing of the valve are done very fast for filter cleaning and consumption of compressed air effectively.

Ordering Number of Diaphragm For Goyen Pulse Valve:

Main Dimension of K5004, K5005, K5002, K5000 Diaphragm:

Product Video of K5004, K5005, K5002, K5000 Membrane:

Pictures of Pulse Valve Diaphragm Production:
