Goyen Pulse Valve CA50T
,
CA50T 2Inch Pulse Valve
,
CA50T Pulse Diaphragm Valve
Goyen Type 2'' CA50T Diaphragm Pulse Jet Solenoid Valve for Dust Collector
This is CA50T Goyen Type Pulse Jet Valve; Reference No: CA50T000, CA50T001, CA50T010, CA50T000-300, CA50T000-305, CA50T000-331, CA50T001-300, CA50T001-305, CA50T001-331, CA50T010-300, CA50T010-305. 2'' inlet and outlet threaded port size; NBR diaphragm; 24V DC, 220V AC (50/60Hz) voltages for you to choose; other voltages can be customized.
Pulse Jet Valve, also called diaphragm valve acts as a “switch” for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device. This system cleans the filter bags cluster by cluster with high-pressure blowing to keep the pressure resistance of the baghouse within a pre-set range, and thus ensure the processing capability and the dust-collecting efficiency of the baghouse.
Technical data of Right Angle Pulse Jet Valves:
Model No
CA15T
CA20T
CA25T
CA35T
CA45T
CA50T
CA62T
CA76T
Nonimal size
φ15
φ20
φ25
φ35
φ45
φ50
φ62
φ76
Port Size
G1/2''
G3/4''
G1''
G1 1/4''
G1 1/2''
G2''
G2 1/2''
G3''
Working pressure
0.3 to 0.8MPa
Temp. range
-5℃ to 55℃
Relative humidity
≤85%
Working
medium
Compressed clean air
Voltage
24VDC, 220VAC
Dimension of CA50T Goyen Type Pulse Jet Valve:
Video of CA50T Goyen Type Pulse Jet Valve:
Detail images of Goyen Type Pulse Jet Valves:
More Goyen Type Pulse Valve For You to Choose:
Threaded Type Immersion Type Dresser Nut Type Flanged Type
RCA Series Solenoid Coil Armature Assembly Pulse Controller
Installation: 1. Prepare supply and blowtube pipes to suit valve specification. Avoid installing valves underneath the tank. 2. Ensure tank and pipes are free from dirt, rust or other particulate. 3. Ensure supply air is clean and dry. 4. Mount valves to inlet pipes and blowtube to valves, ensuring no excess thread sealant can enter the valve itself. 5. Make electrical connections to solenoid or connect RCA pilot port to pilot valve (RCA valves only). 6. Apply moderate pressure to system and check for installation leaks. 7. Fully pressurise system. 8. Test fire and listen for proper actuation and crisp pulse noise.
