| Lugar de origen: | Ningbo, China |
| Nombre de la marca: | BRANDO |
| Certificación: | CE, ISO |
| Número de modelo: | En el caso de los productos de la clase B |
| Cantidad de orden mínima: | 1 por ciento |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Caja, cartón, paleta |
| Tiempo de entrega: | Entre 4 y 7 días hábiles |
| Condiciones de pago: | T/T, PayPal, Western Union |
| Capacidad de la fuente: | 5000 PCS por mes |
| Nombre del producto: | Controlador de pulso | Número de canal: | 24 |
|---|---|---|---|
| Válvula de entrada: | 110VAC | Voltado de salida: | 110VAC |
| Ancho del pulso: | 0.01 a 99.99 segundos | Intervalo de pulso: | 1 a 9999 |
| Intervalo de ciclo: | 1 a 9999 | Aplicación: | Colector de polvo |
| Resaltar: | Pulse Controller 24 Lines,Pulse Controller 110VAC,Dust Collector Controller |
||
24 Lines 110VAC Input 110VAC Output Pulse Valve Controller For Dust Collector
Pulse Controller is a pulse jet bag filter control device in cleaning system, its output signal to control Pulse Jet Valve, blow compressed air bag sequential cleaning, so dust remains in the design within a predetermined range, in order to protect the processing power and dust collecting effect.
1. Channel Number: the number of pulse valves in the equipment (off-line mode is the number of pulse valves in a single chamber);
2. Pulse Width: the working time of the pulse valve (blowing time);
3. Pulse Interval: the interval between 2 pulse valves;
4. Cycle Interval: the interval between the end of one cycle and the start of the next cycle;
Technical Data:
| Model No | BC-08 | BC-10 | BC-12 | BC-16 | BC-20 | BC-24 | BC-30 | BC-36 | BC-52 | BC-64 |
| Channel No | 8 | 10 | 12 | 16 | 20 | 24 | 30 | 36 | 52 | 64 |
| Input Voltage | 24VDC, 110VAC, 220VAC, other can be customized | |||||||||
| Output Voltage | 24VDC, 24VAC, 110VAC, 220VAC, other can be customized | |||||||||
| Pulse Width | 0.1 to 999.9 Seconds | |||||||||
| Pulse Interval | 1 to 9999 Seconds | |||||||||
| Cycle Interval | 1 to 9999 Seconds | |||||||||
| Working Environment | 1. -25°C to +55°C 2. The relative humidity of the air does not exceed 85% 3. No serious corrosion gas and conductive dust 4. No violent vibration or shock |
|||||||||
Detailed Images:
Controller Setting:
Controller Wiring:
Our Production:
Related Products:
|
|
|
|
| Pulse Valve | Solenoid Coil | Solenoid Armature | Diaphragm |
