Name: Danfoss Type 068Z3206 TX2 Thermostatic Expansion Valve 3/8'' x 1/2'' Flare
Brand: Ningbo Brando Hardware Co., Ltd
SKU: TX 2
Price: 65.00 USD
Availability: InStock

Inicio Productos Válvula electromagnética de la refrigeración

Danfoss Type 068Z3206 TX2 Thermostatic Expansion Valve 3/8'' x 1/2'' Flare

Datos del producto:

Lugar de origen:	Porcelana
Nombre de la marca:	BRANDO
Certificación:	None
Número de modelo:	TX 2

Pago y Envío Términos:

Cantidad de orden mínima:	5 piezas
Precio:	Negociable
Detalles de empaquetado:	Caja interior, cartón, plataforma
Tiempo de entrega:	Negociación
Condiciones de pago:	T/T, Western Union, MoneyGram
Capacidad de la fuente:	100000 unidades por mes

Contacto

Descripción detallada del producto

Nombre del producto:	Válvula de expansión termostática	Tamaño de la entrada X la salida:	3/8' x 1/2'
Tamaño de la igualación:	1/4''	Conexión:	Llamarada de la llamarada x
Refrigerante:	R22, R407C	Longitud del tubo capilar:	1,5 m
Equalización de la presión:	Externamente equilibrado	Tamaño de orificio:	0X, 00, 01, 02, 03, 04, 05, 06
Resaltar:	Danfoss TX2 Expansion Valve , TX2 Danfoss R22 R407C expansion valve , Danfoss Tx2 068z3206

Danfoss Type 068Z3206 TX2 Thermostatic Expansion Valve 3/8'' x 1/2'' Flare

A thermal expansion valve or thermostatic expansion valve (often abbreviated as TEV, TXV, or TX valve) is a component in vapor-compression refrigeration and air conditioning systems that controls the amount of refrigerant released into the evaporator and is intended to regulate the superheat of the refrigerant that flows out of the evaporator to a steady value. Although often described as a "thermostatic" valve, an expansion valve isn't able to regulate the evaporator's temperature to a precise value. The evaporator's temperature will only vary with the evaporating pressure, which will have to be regulated through other means (such as by adjusting the compressor's capacity).

Technical Data of T2/TE2 Thermal Expansion Valve:

Model	Equalization	Connection Type	Capillary Tube	Connection (inlet x outlet)		Equalization Connection
				inch	mm
T2	Internal	Flare (SAE)	1.5m	3/8'' x 1/2''	10x12	1/4'' (6mm)
TE2	External
T2	Internal	Solder (ODF)
TE2	External

Ordering Code of T2/TE2 Thermal Expansion Valve:

Connection Type	Equalization	R22	R407C	R134a	R404A/R507	R12
Flare (SAE)	Internal	TX2	TZ2	TN2	TS2	TF2
Flare (SAE)	External	TEX2	TEZ2	TEN2	TES2	TEF2
Solder (ODF)	Internal	TX2	TZ2	TN2	TS2	TF2
Solder (ODF)	External	TEX2	TEZ2	TEN2	TES2	TEF2

Capacity of T2/TE2 Thermal Expansion Valve:

Orifice no	Rated capacity in tons (TR)				Rated capacity in kW
Orifice no	R22	R407C	R134a	R404A/R507	R22	R407C	R134a	R404A/R507
0X	0.15	0.16	0.11	0.11	0.5	0.5	0.4	0.38
00	0.3	0.3	0.25	0.21	1	1.1	0.9	0.7
01	0.7	0.8	0.5	0.6	2.5	2.7	1.8	1.6
02	1.0	1.1	0.8	0.6	3.5	3.8	2.6	2.1
03	1.5	1.6	1.3	1.2	5.2	5.6	4.6	4.2
04	2.3	2.5	1.9	1.7	8	8.6	6.7	6
05	3	3.2	2.5	2.2	10.5	11.3	8.6	7.7
06	4.5	4.9	3.0	2.6	15.5	16.7	10.5	9.1

Dimension of T2/TE2 Thermal Expansion Valve:

Danfoss Type 068Z3206 TX2 Thermostatic Expansion Valve 3/8'' x 1/2'' Flare 0
