Pulse valves (also called diaphragm valves) are the “switch” for compressed air in the dust clean blowing system of the pulse bag filter. It is used to control the release of air pulses in the cleaning cycle. When the dust collector control board starts the cleaning cycle, it sends an electrical signal to the solenoid valve, and then activates the pulse valve. Inside the pulse valve, the rubber diaphragm opens and closes to release the compressed air stored in the air header. At this time, the air enters the blowing pipe above the filter through the valve, and then enters the filter down to clean the filter bag.
Dimension & Data of Armature, Coil for Mecair Pulse Valve:
BRANDO Model
BAPC210030051
Ordeirng Code
CP1/4
Plunger Tube Material
Stainless Steel
Seal Material
NBR, VITON
BRANDO Model
BB10230001
Ordering Code
SB3
Voltage
24VDC, 110VAC, 220VAC
(50/60Hz)
Power
10VA, 19VA, 6W, 15W
Connector
DIN 43650 Form A
Insulation Class
F, H
Video of Solenoid Armature For Mecair Pulse Valve:
BRANDO Solenoid Valve Armature Production Video:
More Products For Mecair Pulse Valve for you to choose:
Valve Diaphragm
Solenoid Coil
Solenoid Armature
Pulse Controller
